Oracle Cloud Infrastructure Documentation

Reference for Object Storage

This guide lists the predefined objects in Resource Analytics for Oracle Object Storage. You can find information about views, entity relationships, subject areas, and sample queries.

Views

This section provides information about views within Resource Analytics Object Storage and their columns, data types, keys, and the referred view and column names. The following views are available:

Object Storage Views
NameDescription
OBJECT_STORAGE_BUCKET_DIM_VThis view stores information on buckets, which are storage containers for objects within a compartment and namespace in Oracle Cloud Infrastructure Object Storage.
OBJECT_STORAGE_BUCKET_FACT_VFact table for OCI Object Storage Bucket Service.

The suffixes in the view names specify the view type:

  • FACT_V: Fact
  • DIM_V: Dimension

Relationship Diagram

This section provides diagrams that define the logical relationship of a fact table with different dimension tables.

The contents of each view and their relationships are listed in the following file: Object Storage views.

This diagram shows the relationship of the Object Storage Bucket fact view with different dimension views.

OBJECT_STORAGE_BUCKET_FACT_V
Relationship diagram showing the fact table, OBJECT_STORAGE_BUCKET_FACT_V connected to two dimension tables, OBJECT_STORAGE_BUCKET_DIM_V and COMPARTMENT_DIM_V.

Sample Queries

Sample queries for Object Storage.

List the details of all Object Storage buckets and their sizes:
SELECT COMPARTMENT_ID, BUCKET_ID, OBJECT_COUNT, TOTAL_SIZE_BYTES
FROM OCIRA.OBJECT_STORAGE_BUCKET_FACT_V;

Data Lineage

The Customer Experience Semantic Model Lineage spreadsheet and Metric Calculation Logic spreadsheet for Object Storage provides an end-to-end data lineage summary report for physical and logical relationships in your data.

For more information, see Data Lineage.

Subject Areas

This section provides information on the subject areas with data you maintain in Object Storage. These subject areas, with their corresponding data, are available for you to use when creating and editing analyses and reports. The information for each subject area includes:

  • Description of the subject area.

  • Business questions that can be answered by data in the subject area, with a link to more detailed information about each business question.

  • Job-specific groups and duty roles that can be used to secure access to the subject area, with a link to more detailed information about each job role and duty role.

  • Primary navigation to the work area that's represented by the subject area.

  • Time reporting considerations in using the subject area, such as whether the subject area reports historical data or only the current data. Historical reporting refers to reporting on historical transactional data in a subject area. With a few exceptions, all dimensional data are current as of the primary transaction dates or system date.

  • The lowest grain of transactional data in a subject area. The lowest transactional data grain decides how data are joined in a report.

  • Special considerations, tips, and things to look out for in using the subject area to create analyses and reports.

The subject area is:
