OCI Cache

Using the OCI Cache subject area, you can create reports about the Redis-based cache resources, including clusters and associated network attributes.

Business Questions

The subject area can answer the following business questions:

  • Number of Cache clusters
  • Network associated with the Cache clusters (VCN, Subnet)
  • Cache users
  • Cache configurations for the clusters
  • Sharded cluster vs. non-sharded cluster
  • Number of nodes, memory size in the drill-down report

Logical Model

The OCI Cache subject area is based on a relationship-driven logical model.

An OCI Cache Redis Cluster fact table is connected to the following dimension tables:


Fact table OCI Cache Redis Cluster connected to six dimension tables, Tenancy, Compartment, Date, Region, Config Set, and Redis Cluster.

An OCI Cache Node fact table is connected to the following dimension tables:


Fact table OCI Cache Node Fact connected to five dimension tables, Tenancy, Compartment, Date, Region, and OCI Cache Node Summary.

Metric Details

The fact folders in this subject area show the following metrics:

Metric Details for OCI Cache
MetricDescription
Node CountThe number of nodes per shard in the cluster when clusterMode is SHARDED. This is the total number of nodes when clusterMode is NONSHARDED.
Node Memory in GbsThe amount of memory allocated to the nodes of the cluster, in gigabytes.
Shard CountThe number of shards in a sharded cluster. Only applicable when clusterMode is SHARDED.
